| Type: | PNP |
| Pin Count: | 3 |
| Maximum Collector Emitter Voltage: | 250 V |
| Maximum DC Collector Current: | 17 A |
| Minimum DC Current Gain: | 55@1A@5V |
| Maximum Operating Frequency: | 30(Typ) MHz |
| Maximum Collector Emitter Saturation Voltage: | 3@0.8A@8A V |
| Maximum Collector Base Voltage: | 250 V |
| Operating Temperature: | -50 to 150 ℃ |
| Maximum Power Dissipation: | 130000 mW |
| Mounting: | Through Hole |
| Rad Hard: | No |
| Type: | PNP |
| Pin Count: | 3 |
| Maximum Collector Emitter Voltage: | 45 V |
| Maximum DC Collector Current: | 0.1 A |
| Minimum DC Current Gain: | 220@2mA@5V |
| Maximum Operating Frequency: | 100(Min) MHz |
| Maximum Collector Emitter Saturation Voltage: | 0.3@0.5mA@10mA|0.65@5mA@100mA V |
| Maximum Collector Base Voltage: | 50 V |
| Operating Temperature: | -55 to 150 ℃ |
| Maximum Power Dissipation: | 300 mW |
| Mounting: | Surface Mount |
| Rad Hard: | No |
| Type: | NPN |
| Pin Count: | 3 |
| Maximum Collector Emitter Voltage: | 20 V |
| Maximum DC Collector Current: | 5 A |
| Minimum DC Current Gain: | 280@500mA@2V |
| Maximum Operating Frequency: | 150(Typ) MHz |
| Maximum Collector Emitter Saturation Voltage: | 0.5@60mA@3A V |
| Maximum Collector Base Voltage: | 60 V |
| Operating Temperature: | -55 to 150 ℃ |
| Maximum Power Dissipation: | 1000 mW |
| Mounting: | Through Hole |
| Rad Hard: | No |
| Type: | PNP |
| Pin Count: | 3 |
| Maximum Collector Emitter Voltage: | 45 V |
| Maximum DC Collector Current: | 0.5 A |
| Minimum DC Current Gain: | 40@500mA@1V |
| Maximum Collector Emitter Saturation Voltage: | 0.7@50mA@500mA V |
| Maximum Collector Base Voltage: | 50 V |
| Operating Temperature: | -55 to 150 ℃ |
| Maximum Power Dissipation: | 900 mW |
| Mounting: | Surface Mount |
| Rad Hard: | No |
| Type: | NPN|PNP |
| Pin Count: | 6 |
| Maximum Collector Emitter Voltage: | 45 V |
| Maximum DC Collector Current: | 0.5 A |
| Minimum DC Current Gain: | 160@100mA@1V|100@300mA@1V |
| Maximum Operating Frequency: | 170(Typ) MHz |
| Maximum Collector Emitter Saturation Voltage: | 0.7@50mA@500mA V |
| Maximum Collector Base Voltage: | 50 V |
| Operating Temperature: | -65 to 150 ℃ |
| Maximum Power Dissipation: | 330 mW |
| Mounting: | Surface Mount |
| Type: | NPN |
| Pin Count: | 3 |
| Maximum Collector Emitter Voltage: | 50 V |
| Maximum DC Collector Current: | 15 A |
| Minimum DC Current Gain: | 200@2A@10|50@10A@2V |
| Maximum Collector Emitter Saturation Voltage: | 0.4@375mA@7.5A V |
| Maximum Collector Base Voltage: | 60 V |
| Operating Temperature: | -55 to 150 ℃ |
| Maximum Power Dissipation: | 23000 mW |
| Mounting: | Through Hole |
| Rad Hard: | No |
