電氣特性 Features
| Configuration: | Single |
| Channel Type: | N |
| Maximum Drain Source Voltage: | 30 V |
| Maximum Continuous Drain Current: | 10 mA |
| Maximum Gate Source Voltage: | -30 V |
| Operating Temperature: | -55 to 150 ℃ |
| Mounting: | Surface Mount |
| Rad Hard: | No |
2SK3666-4-TB-E
